Thursday, January 31, 2013

Deletion State Codes Fields Preventing Solution Import


If you have upgraded a CRM database from 4.0. to 2011 you may have some leftover fields that end in dsc.  These fields can later on come back to haunt you by showing up as missing components when import a solution into 2011. The fields will always end in “dsc” as you can see in the image below.

John Hoven has written a SQL script which will remove these attributes from the database.  After removing them re-export the solution and attempt the import again.
-- Delete the custom DSC attributes from the database.

DELETE a
--select A.LogicalName
FROM   metadataschema.attribute a

INNER JOIN metadataschema.entity e

ON e.entityid = a.entityid
WHERE  a.attributeof IS NOT NULL

AND a.attributetypeid = '00000000-0000-0000-00AA-110000000019'

AND a.logicalname LIKE '%dsc'

AND a.iscustomfield = 1
-- Delete the dsc attribute map columns
DELETE am
--select AM.*
FROM   dependencybase db

INNER JOIN dependencynodebase dnb

ON db.dependentcomponentnodeid = dnb.dependencynodeid

INNER JOIN attributemapbase am

ON am.attributemapid = dnb.objectid
WHERE  db.requiredcomponentnodeid IN (SELECT dnb.dependencynodeid

FROM   dependencynodebase dnb

LEFT JOIN metadataschema.attribute

a

ON dnb.objectid = a.attributeid

WHERE  dnb.componenttype = 2

AND a.logicalname IS NULL)
-- delete attribute map required dependencies on dsc columns
DELETE db
FROM   dependencybase db

INNER JOIN dependencynodebase dnb

ON db.dependentcomponentnodeid = dnb.dependencynodeid
WHERE  db.dependentcomponentnodeid IN (SELECT dnb.dependencynodeid

FROM   dependencynodebase dnb

LEFT JOIN metadataschema.attribute

a

ON dnb.objectid = a.attributeid

WHERE  dnb.componenttype = 2

AND a.logicalname IS NULL)
-- Delete the attribute dependencies on dsc columns
DELETE db
FROM   dependencybase db

INNER JOIN dependencynodebase dnb

ON db.dependentcomponentnodeid = dnb.dependencynodeid
WHERE  db.requiredcomponentnodeid IN (SELECT dnb.dependencynodeid

FROM   dependencynodebase dnb

LEFT JOIN metadataschema.attribute
                                                       a

ON dnb.objectid = a.attributeid

WHERE  dnb.componenttype = 2

AND a.logicalname IS NULL)
-- Delete the dependency nodes
DELETE dnb
-- select A.LogicalName
FROM   dependencynodebase dnb

LEFT JOIN metadataschema.attribute a

ON dnb.objectid = a.attributeid
WHERE  dnb.componenttype = 2

AND a.logicalname IS NULL
